Jitong film faced plywood

Jitong Film Faced Plywood

Specifications and parameters

JiTong-Form Hardwood (Eucalyptus) JITONG-H I
Panel Size	4'x8' 3'x6' or Cut size at customer's request
Thickness	6mm-21 mm
Thickness Tolerance	±0.4mm to ±0.5mm
Veneer Core	Whole Piece Face Eucalyptus
Moisture Content	8%-14%
Glue	WBP Phenolic
Film Face/Back	Finland Dynea PSF(Phenolic Surface Film) Mirror
Film Color	Black, Brown, Red, Printing logo
Film Grammage	160g/m²
Hot Press	Three Times
Approximate kg/m³	650kg/m³-700kg/m³
Approximate Reusage	More than 25 Times
Conveyance (18mm for reference)	20GP	8 pallets/ 22m³, 55pcs/pallet
	40GP	16 pallets/ 42m³, 55pcs/pallet
	40HQ	18 pallets/53m³, 55pcs/pallet

Details of film faced plywood

Features and characteristics

Using high-strength phenolic glue,without delamination
Imported Finland film covered, beautiful mirror surface
Uniform thickness
Material and labor saving
Quality and safety, environmental protection
Waterproof, Wear-resistant, anti-cracking.

Applications of eucalyptus formwork plywood

Concrete building construction

Other concrete construction engineering (bridges, dam, tunnels, power stations etc)

Matched with steel/aluminium alloy frame, serving as wall/slab/column fromwork panels, forming construction formwork systems.

Usage of Jitong plywood in construction site

Actual result after using Jitong plywood

Our finished projects

Fuqing nuclear power engineering in Fujian province
Haiyan nuclear power engineering in Zhejiang province
Jinan Olympic sports center
Beiyuan viaduct in Jinan

Production flow chart
Rotary cutting of veneer-drying-sorting(scarf-jointing,jointing,patching)-bonding-cold press-hot press-sanding-grading-cold press-hot press-coating-edge sealing-inspection-packing-storage

Quality comparison
our featured product Eucalyptus plywood formwork compared with poplar plywood formwork, in the case ofsize:1830*915mm(3feet*6feet), thickness:13.8mm.

Certifications
We, Shandong Jitong Formork Co.,Ltd, obtained the certification of ISO9001 and many awards and certificates.

Packing details

Strong and high pallets to avoid damage by fork lift;
Inner plastic film to prevent water; Outer carton or plywood to prevent scratch
More steel or woven straps to ensure the stability of package
Fortified angle bead.

Company profile
We, Shandong Jitong Formwork Co. Ltd, are manufacturer and exporter of concrete formwork plywood, main products including: bamboo plywood, bamboo bridge plywood, poplar plywood and encalyptus plywood.
We own advanced production equipment, professional quality control system and sufficient stock, which can meet your requirements for quality and delivery.
Welcome cooperation!
